Ranheat biomass boilers use wood waste to heat hot water, which can be piped around your warehouse to your existing space heaters, or used for process heating.
Our range of industrial wood waste boilers can save you money, reducing wood waste to landfill, and providing cost effective, sustainable heat.
There are four models in the Ranheat MSU range biomass boiler:
All MSU burners can dispose of both natural and manmade wood waste products, providing heat outputs from 150-600kW and disposal for 0.5 tons to 16 tons a week.
How much wood waste do you need to dispose of per week? Alternatively, how much heat do you need to generate? And where do you need it? Our team can advise you on the right biomass system for your business.
Wood waste boilers for industrial heating
Ranheat biomass boilers can comfortably heat various spaces within your factory, warehouse, or office premises using LTHW (Low Temperature Hot Water, typically 90oC). See how much heat you could generate from your wood, chippings, shavings or dust:
| Biomass boiler model | Heat output | Area heated (approx.) |
| MSU 150 | 150kW, 500,000Btu/hr | 1500m2 |
| MSU 300 | 300kW, 1,000,000Btu/hr | 3000m2 |
| MSU 450 | 450kW, 1,500,000Btu/hr | 4500m2 |
| MSU 600 | 600kW, 2,000,000Btu/hr | 6000m2 |
Our range of biomass boilers suit varying amounts and types of wood waste. See how much heat you could be generating instead of using skips or landfill for your offcuts and sawdust:
| Warm Air burner model | Tons/Week | Heat output | Area heated (approx.) |
| MSU 150 | 0.5-4 | 150kW 500,000Btu/hr | 500-1000m2 |
| MSU 300 | 3-8 | 300kW 1,000,000Btu/hr | 1000-2000m2 |
| MSU 450 | 6-12 | 450kW 1,500,000Btu/hr | 3000-4000m2 |
| MSU 600 | 10-16 | 600kW 2,000,000Btu/hr | 4000-5000m2 |
We also supply Warm Air heaters WA Range, and specialist custom systems for larger requirements High Temperature Hot Water (HTHW) and steam for process heating.
The short version is that your wood waste – that is, offcuts, MDF, OSB, chippings, pellets, or even dust – goes into a combustion chamber. This feed can be a manual, or automated.
The combustion fires a heat exchange process, creating hot water at around 95oC (LTHW). Take this to feed your existing heat system, direct it for process heating, or convert to warm air for space heating.
We also supply Warm Air heaters, Ranheat WA range, and specialist custom, Ranheat Multi Range, systems for High Temperature Hot Water (HTHW) and steam for process heating.
This does depend on the requirements. We have different silo sizes, types of silos, combustion chambers so that you can get the right system for. Our MSU range typically costs between £40-250k, with most installations eventually paying for themselves in savings to the cost of wood waste disposal, and reduction in gas and electricity bills.
We have years of experience, and our team are always happy to advise which biomass boiler system is the best for your site – give us a call. Contact
Low carbon
Financial incentives
Reduce waste costs
Renewable energy from waste
Powerful heat source
Automated and easy
Investigate the Numbers
The numbers add up…
Lorem ipsum dolor sit amet, consectetuer adipiscing elit, sed diam nonummy nibh euismod tincidunt ut laoreet dolore magna aliquam erat volutpat. Ut wisi enim ad minim veniam, quis nostrud exerci tation.
Ranheat have worked with business of all sizes over our 25 years of experience. Our friendly and knowledgeable team can consult, guide and advise on how to get the best value for money from a biomass boiler or warm air system.
We manufacture, build, install and service wood-fired heating systems throughout the UK from our base in Northampton. We provide a complete end-to-end service. With all key skills in house and no lengthy supply chains for components, we understand every inch of your install, minimising downtime.
